Red Laser & LED Bar / LB-16XR Technical Parameters:

Parameter
LED:
Power requirements: 110-240V/50-60Hz (±10%)
Consumption: max. 80W
LED Source: 8pcs CREE XPE 3W
Driving Current: 700 mA
Color Temp.:2700-2900K
Beam Angle: 6 degree


Laser:
Laser Source: 8pcs 200mW Red laser module, with individual Angle Regulator
Driving Current: 260 mA
Laser wavelength: 638nm Red
Laser Class: 3B


Other Configuration
Appearance Color: Black
Control Protocol:DMX-512
Channel Mode: 10Ch and 22Ch both are inside menu
Control Signal: DMX-512/Stand alone/Master and slave/Sound Active
Stand Alone Mode: 4 dynamic effect/2 sound active dynamic effect
Rotation: X-axis is constant. Y-axis is 180 degree.
Dimming: From 0 to 100 linear dimming, smooth dimming with no vision shock in low DMX value
Connector: Signal line In/Out; Power line In/Out
Heat Dissipation: Fan cooling system
Application Occasion: Indoor
Operation Temperature: -20℃ to 40℃
Housing material: Tensile aluminum, surface electrostatic powder coating

The stage light bar uses of laser module and LED module of combination, which have more vision layering and fantasy stage effect compare with tradition mode.

Especial for kind of small budget of stage show and little concert, it would not have cost you too much money to afford two kinds of lighting device that laser systems and LED group, we just fuse them together, and that is really kill two birds whit one stone.

And I suppose this price is what may get your most wondering, in the matter of fact, the price of kind of stage light is about 75% of the total price of buy separately, that means you just need pay extra 50% money and then get a additional item, and we solve off the problem of how to arrange the device position, that would give your stage more mystery and fantasy.





shooting image
