Nano G1 Specification:
Parameter:
Power requirements: 110-230V/50Hz (±5%)
Consumption: max. 130W
Total optical output: 1.000mW
Laser module:Manufatured in Europe
Laser Balance:Single Green
520nm 1.000mW
Beam diameter: 3.5x4.0mm
Divergence: <0.8mrad
Modulation: 0-5V analog, up to 100kHz TTL
Scanner set:DT-30 30Kpps Max.60Deg
Input connector: ILDA IN DB25 male
Output connector: ILDA OUT DB25 female
Operation temperature: 10-35°C (-20℃ to +40℃）
Size:281*268*173mm
Weight: 8.9kg
Feature:
1. Laser diode module entirely manufactured in Europe.
2. The lowest output power of the series.
3. Good choice for low cost budge, good cost performance ratio.
4. Individual controller for brightness, X/Y size and reverse phase
5. Easy setup and use the X/Y mirror.
6. Self-developed design: temperature system and handle
7. Industiral design, fashion and has good visual hidden
8. It can be equiped the self-developed temperature control system
Nano-G1_Green Laser Show Projector
Nano_G1 is a 1W green laser light projector, which use diode laser module manufactured
in Europe, suitable to small venues of laser
animation shows, displays and graphics, as well the 3D laser man show.
This model can run up the Phoenix Pro version, add the curtain, then comes the laser man show
Unique
self-developed handle is assembled into this model, it can make device use in
different spaces, hanging up and hanging side even upside down.
Unique handle design
It can be equipde the self-developed temperature control system, make this device well function between -20℃ to 40℃.
Nano_G1
is suitable for small venue like bar, club; wedding celebration and 3D laser
man show needed good quality laser system, especial for the laser man show,
which is a low cost chose with it has good cost performance ratio.
ANNOUNCEMENT: This kinds of landmark laser projector is self-developed by Supercan CO.,LIT, which is the only official certificated productions in mainland China.
Do not believe other websites false info; my company reserves the right to pursue legal action.
READ THE CERFICATE AND PETENT
KNOW MORE ABOUT LASER SHOW
